Security lock (comparable with security grade 3 according to
EN 12209). The hardened hook bolt with intermediate locking
position is locked and retracted by turning the key 360°.
The deadbolt protrudes 23 mm.
The lock can be used with DIN standard fittings.
Drilling protection 404252-B, is available as an
optional accessory.
4232X is the microswitch version of the lock.
The switch changes the status during the last
key throw to the locking direction.
Striker plate 0036, 0065, LP763
Finish Fe/ZL
Cylinder Euro DIN
Fire resistance –
